Networks You Can Deploy

Moving agents to separate processes usually means rewriting the networking layer. With the AG2 Network, it's a constructor argument.

The Hub absorbs the topology difference. Replace LocalLink with WsLink, add an auth registry, and your agents are distributed. This post covers the three things you actually wire up to go from a local prototype to a network you can deploy.

This is the fourth post in a four-part series on the AG2 Network:

1. One Coherent Agent Isn't Enough — the action-driven network; Hub, HubClient, Channel, Adapter.
2. Choreography You Can Dial In — expectations, audience addressing, TransitionGraph.
3. What Survives, Survives Exactly — write-ahead log, three identity records, audit log.
4. Networks You Can Deploy (this post) — WebSocket transport, authentication, at-least-once delivery.

Crossing the Process Boundary#

In the previous posts every example used LocalLink — an in-process link that connects a HubClient to a Hub object in the same Python process. Swapping to WebSocket is a single-line change on the client side:

# In-process (development)
from autogen.beta.network import LocalLink

hc = HubClient(LocalLink(hub))  # hub is a Hub object in this process

# Cross-process (production)
from autogen.beta.network import WsLink

hc = HubClient(WsLink("ws://hub:8765"))  # hub is a running process elsewhere

The hub process itself runs serve_ws — an async context manager that binds a WebSocket server to an existing Hub:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14

import asyncio
from pathlib import Path

from autogen.beta.knowledge import DiskKnowledgeStore
from autogen.beta.network import Hub, serve_ws

async def main() -> None:
    hub = await Hub.open(DiskKnowledgeStore(Path("./hub-data")))
    async with serve_ws(hub, "0.0.0.0", 8765) as server:
        host, port = server.sockets[0].getsockname()
        print(f"hub listening on ws://{host}:{port}")
        await asyncio.Future()  # run until interrupted

asyncio.run(main())

Agent processes are entirely separate Python programs. Each constructs its own WsLink and HubClient:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

import asyncio

from autogen.beta import Agent
from autogen.beta.config import AnthropicConfig
from autogen.beta.network import (
    EV_TEXT,
    HubClient,
    Passport,
    Resume,
    WsLink,
)

HUB_URL = "ws://hub:8765"

async def main() -> None:
    hc = HubClient(WsLink(HUB_URL))
    alice = await hc.register(
        Agent("alice", prompt="You coordinate tasks.", config=AnthropicConfig(model="claude-sonnet-4-6")),
        Passport(name="alice"),
        Resume(summary="coordinator"),
    )

    channel = await alice.open(type="consulting", target=["bob"])
    await channel.send("What is the current deployment status?")

    await alice.wait_for_channel_event(
        channel_id=channel.channel_id,
        predicate=lambda e: e.event_type == EV_TEXT and e.sender_id != alice.agent_id,
        timeout=60.0,
    )
    await hc.close()

asyncio.run(main())

Everything else — open, send, wait_for_channel_event, peers, read_wal, on_envelope — is identical to the in-process API. The hub's protocol is the same regardless of whether the link goes through in-process queues or a real WebSocket.

One topology change, zero agent-code changes. The agent doesn't know or care whether its HubClient speaks to a local object or a remote process.

Authentication: Knowing Who's Connecting#

When agents run in separate processes, the hub needs to verify that a connecting client really is who it claims to be. The default is NoAuth — every connection is accepted. For a deployed system, use ApiKeyAuth.

Configuring the hub#

Pass an AuthRegistry to Hub.open. The registry maps scheme names to adapters; ApiKeyAuth handles the "api_key" scheme:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16

from autogen.beta.knowledge import DiskKnowledgeStore
from autogen.beta.network import ApiKeyAuth, AuthRegistry, Hub, serve_ws

AGENT_KEYS = {
    "alice": "ak-alice-f3a2b1",
    "bob":   "ak-bob-9c8d7e",
    "carol": "ak-carol-5f4e3d",
}

async def main() -> None:
    hub = await Hub.open(
        DiskKnowledgeStore("./hub-data"),
        auth=AuthRegistry([ApiKeyAuth(keys=AGENT_KEYS)]),
    )
    async with serve_ws(hub, "0.0.0.0", 8765):
        await asyncio.Future()

ApiKeyAuth uses constant-time comparison (hmac.compare_digest) so token-rejection latency doesn't leak which prefix matched.

Configuring each agent process#

Each agent's Passport carries an AuthBlock that tells the hub which scheme to validate and what claim to present:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11

from autogen.beta.network import AuthBlock, HubClient, Passport, Resume, WsLink

hc = HubClient(WsLink("ws://hub:8765"))
alice = await hc.register(
    Agent("alice", ...),
    Passport(
        name="alice",
        auth=AuthBlock(scheme="api_key", claim={"token": "ak-alice-f3a2b1"}),
    ),
    Resume(),
)

If the token is wrong or the name has no registered key, the hub raises AuthError at the handshake — before any envelope is accepted or dispatched. Unknown agents get no information beyond rejection.

Dynamic key resolution#

For large deployments where key-per-name static dicts don't scale, pass a resolver instead:

async def resolve_key(name: str) -> str | None:
    """Return the expected token for `name`, or None if unknown."""
    return await secrets_manager.get(f"agent/{name}/api_key")

auth = AuthRegistry([ApiKeyAuth(resolver=resolve_key)])

The resolver is tried as fallback when the name is not in keys. Return None to reject.

At-Least-Once Delivery#

In-process agents don't drop messages — if the hub dispatches to a LocalLink client, the client receives it. Over WebSocket, connections close. Processes restart. The network partition you planned around happened anyway.

The AG2 Network solves this with at-least-once delivery: the hub tracks which envelopes each agent has acknowledged. If a connection drops before an EV_TEXT is acked, the hub doesn't forget it — the next connection from that agent replays it.

How replay works#

Every HelloFrame that opens a WebSocket connection carries an optional since_envelope_id — the agent's high-water mark. When set, the hub replays all unacked envelopes addressed to this agent with envelope_id strictly greater than that mark, then resumes live traffic.

HubClient.attach is the reconnect-aware entry point. It binds the same identity (same agent_id, same WAL history) to a fresh connection:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

from autogen.beta.network import HubClient, Passport, Resume, WsLink

# Original node (simulating a process that dropped)
bob_hc1 = HubClient(WsLink("ws://hub:8765"))
bob1 = await bob_hc1.register(Agent("bob", ...), Passport(name="bob"), Resume())
# ... connection drops; alice's message arrived but was never acked

# Fresh process: attach under the same name; hub replays the missed envelope
bob_hc2 = HubClient(WsLink("ws://hub:8765"))
bob2 = await bob_hc2.attach(
    Agent("bob", ...),
    name="bob",
    since_envelope_id="",  # "" = replay everything the hub has not seen acked
)
# bob2 receives alice's message again and replies normally

bob2.agent_id == bob1.agent_id — the identity is the same. The channel WAL grows in place. From the other participants' perspective, bob had a brief pause, not a death.

since_envelope_id values#

Finishing interrupted turns#

Replay re-delivers missed envelopes. But if the agent was already mid-turn — it had received the envelope and started processing — replay won't re-fire. Call resume_pending_turns() after attach() to re-fire any turn the channel protocol is waiting for:

bob2 = await bob_hc2.attach(Agent("bob", ...), name="bob", since_envelope_id="")
replayed = await bob2.resume_pending_turns()
# replayed = number of pending turns re-fired

resume_pending_turns asks the hub for any PendingTurn entries, fetches each turn's triggering envelope from the WAL, and feeds it back through the notify handler. It is idempotent: if a prior reply already landed, the handler can short-circuit so the same logical turn is not posted twice.

What the hub guarantees: if an envelope was WAL-appended, it will be delivered to every addressed participant — eventually, exactly once in logical terms. The transport may deliver it more than once; the handler is responsible for idempotency.

HubBackedCheckpointStore: Durable Task State#

Agents that do long-running LLM tasks need to survive a process restart mid-task. HubBackedCheckpointStore delegates checkpoint_task / read_task_checkpoint to the hub's KnowledgeStore, so task state is durable wherever the hub persists its own data (DiskKnowledgeStore, RedisKnowledgeStore, …):

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15

from autogen.beta.network import HubBackedCheckpointStore, HubClient, WsLink

hc = HubClient(WsLink("ws://hub:8765"))
checkpoint_store = HubBackedCheckpointStore(hc)

alice = await hc.register(
    Agent(
        "alice",
        prompt="You run long multi-step research tasks.",
        config=AnthropicConfig(model="claude-sonnet-4-6"),
        checkpoint_store=checkpoint_store,
    ),
    Passport(name="alice"),
    Resume(claimed_capabilities=["research"]),
)

The store accepts either a Hub (in-process) or a HubClient (cross-process) — the API is identical, and the durability tracks wherever the hub stores its data. Agents that don't need cross-process durability can use any other CheckpointStore implementation, or omit checkpointing entirely.

Dynamic Membership#

Agents can register and unregister at runtime. The hub handles this without restarting:

# New agent joins the network
carol = await hc.register(Agent("carol", ...), Passport(name="carol"), Resume())

# Agent leaves cleanly
await carol.unregister()

After unregister, carol's identity records are removed from disk and the hub's registry caches are updated. Any open channels carol was participating in remain open; her agent_id is simply absent from future peers results.

The Federation Seam#

The RemoteAgentProxy Protocol is the hub's seam for cross-org federation. When a participant's passport carries kind="remote_agent", the hub routes envelopes to it through a registered proxy rather than a local endpoint. No proxies ship in the framework — each tenant implements the wire protocol they need (A2A, gRPC, HTTP, message bus) and registers it:

hub.register_remote_proxy(MyA2AProxy(scheme="a2a", target_url="https://partner.example.com/a2a"))

From the channel's perspective, a remote_agent participant is indistinguishable from a local one. It sends envelopes the same way and its messages appear in the same WAL.

Where to Next#

• The Agent Harness: An Agent Is More Than a Loop — what's inside each node in the network: Stream, middleware, tools, observers, HITL, memory.
• Docs: Hub & Identity · Network Quick Start · Channel Adapters Overview

The three previous posts described the protocol. This one described the deployment. The two together are the full picture: a network that is durable by construction, authenticated from the handshake, and capable of surviving the failures that always eventually happen.
